Making a Rotating Icon Button in React

Making a Rotating Icon Button in React

If you haven't already, try changing the theme on this blog by clicking the button in the top right corner of the webpage. You'll notice a fun detail: as you cycle between the themes, the icons will "rotate" in from bottom to top.

Kinda cool, right?

In design, We call these little details microinteractions1. Small, surprising and hopefully delightful, these animations can give an outsized amount of character to an otherwise boring, functional user interface.

In this post, I'll show you how to build a rotating icon button like mine in React. If you're just looking for the code, feel free to skip to the end or click here for the code sandbox.

Ok, let's get started!

Setup

If you'd like to follow along, you can fork this CodeSandbox.

Let's start by creating a new React app and adding our dependencies. For this article, I'll be using styled-components to handle styling and react-feather for icons. I'm going to use three icons: Sun, CloudRain, and Moon.

We'll also need a component for our button, RotatingIconButton. Our app is going to return this button with our three icons as its children.

import React from "react"
import { Sun, CloudRain, Moon } from "react-feather"
import styled from "styled-components"

export default function App() {
  return (
    <RotatingIconButton>
      <Sun />
      <CloudRain />
      <Moon />
    </RotatingIconButton>
  )
}

function RotatingIconButton({ children }) {
  return <button>{children}</button>
}

This should give us something like this:

Ok, that's good for now. Let's move on to our button's styles.

Styling the Button

Before we get into our animations, let's first style up our button. By default, we want all of the button's children to be piled on top of one another in the center of the button.

To get this done, I'll create our first styled component, Button.

const Button = styled.button`
  height: 48px;
  width: 48px;
  position: relative;
  padding: 0px;
`

Next, I'll create a second component, Icon, that we'll use to wrap our icons.

const Icon = styled.div`
  position: absolute;
  top: 0px;
  height: 100%;
  width: 100%;
  display: flex;
  align-items: center;
  justify-content: center;
`

And now let's put these pieces together in the RotatingIconButton component.

function RotatingIconButton({ children }) {
  return (
    <Button>
      {React.Children.map(children, (child, i) => {
        return <Icon>{child}</Icon>
      })}
    </Button>
  )
}

We should end up with a big pile of centered icons in the middle of our button:

Now let's work out our button's state.

The Button State

Out button can have any number of children but we only want it to show one child at a time. The button will need to keep track of which of these children is its currently active child.

We can create this state using the useState React hook, and we'll store the array index of the button's currently active child. As we render each child, we can compare its index against this value to see whether that child is the currently active one.

function RotatingIconButton({ children }) {
  const [current, setCurrent] = React.useState(0)

  return (
    <Button>
      {React.Children.map(children, (child, i) => {
        const isCurrent = i === current

        return <Icon key={i}>{child}</Icon>
      })}
    </Button>
  )
}

We're not using this isCurrent variable yet, but we'll come back to it soon.

Each time we click the button, we'll want to bump up that current value so that it cycles through the children. In our click event handler, we'll also need to check whether we're already at our last index (children.length - 1) so that we can loop back around to zero when we've reached the end.

function RotatingIconButton({ children }) {
  const [current, setCurrent] = React.useState(0)

  function cycleCurrent() {
    if (current === children.length - 1) {
      setCurrent(0)
    } else {
      setCurrent(current + 1)
    }
  }

  return (
    <Button onClick={cycleCurrent}>
      {React.Children.map(children, (child, i) => {
        const isCurrent = i === current

        return <Icon key={i}>{child}</Icon>
      })}
    </Button>
  )
}

We now have everything we need to animate our icons.

Animating the Icons

On each render, we want our icons to perform two different animations depending on whether that icon is active or not.

If the icon is our new currently active icon, we want it to move from below the button up to the center of the button. If not, we'll instead want it to move from the center of the button to up above the button; or, if it's already above the button, to stay where it is.

We'll use the Icon element's transfrom property to make these moves, but we have two options for how to actually animate the element: the transition property and the animation property.

Let's look at transition first.

Animating with Transition

The transition property allows us to define an animation to apply whenever certain properties change. In React, we can define a different transform value on each update based on isCurrent.

export function RotatingIconButton({ children }) {
  /* snip */

  return (
    <Button onClick={cycleCurrent}>
      {Children.map(children, (child, i) => {
        const isCurrent = i === current

        return (
          <Icon
            key={i}
            style={{
              transition: "transform .5s",
              transform: `translateY(${isCurrent ? 0 : -100}%)`,
            }}
          >
            {child}
          </Icon>
        )
      })}
    </Button>
  )
}

Here's what that code (with its snips unsnipped) will give us:

That's admittedly fun—but it isn't what we wanted. Rather than everything moving in and out from the top, we wanted the new active icon to come in from the bottom.

This is a problem for the transition property. It doesn't give us a way to "jump" to our "from" position before transitioning to our "to" position, so we've have no way of getting from above to below without crossing back down through the middle. We could do some clever tricks here with effect hooks, requestAnimationFrame, and timings... but we don't have to.

We can use CSS animations instead.

Animating with CSS Animations

To use a CSS animation, we'll first need to define the animation as a set of keyframes.2 For this animation, we need two sets of keyframes: riseIn will move an element from a lower position to its default position; and riseOut will move the element from its default position to a higher position.

import styled, { keyframes } from "styled-components"

const riseIn = keyframes`
  from {
    transform: translateY(100%);
  }
  to {
    transform: translateY(0%);
  }
`

const riseOut = keyframes`
  from {
    transform: translateY(0%);
  }
  to {
    transform: translateY(-100%);
  }
`

Now we can modify our Icon styled component to use these animations. We'll pass the Icon component a new prop, isCurrent, that will determine which animation it should use.

const Icon = styled.div`
  position: absolute;
  top: 0px;
  height: 100%;
  width: 100%;
  display: flex;
  align-items: center;
  justify-content: center;
  animation-fill-mode: forwards;
  animation-name: ${(props) => (props.isCurrent ? riseIn : riseOut)};
`

Let's see how that looks:

It may still look a little strange, but if we hide the overflow on the button...

const Button = styled.button`
  height: 48px;
  width: 48px;
  position: relative;
  padding: 0px;
  overflow: hidden;
`

Then we get this:

There we go! We have our animation.

Final Touches

There are a few last details to take care of before I'll call this done.

First, let's style up our button, getting rid of its background and border and giving it a hover effect.

const Button = styled.button`
  height: 48px;
  width: 48px;
  position: relative;
  padding: 0px;
  overflow: hidden;
  cursor: pointer;
  outline: none;
  border-radius: 4px;
  background: transparent;
  border: none;

  &:hover {
    background: rgba(144, 144, 144, 0.1);
  }
`

Though it's probably hard to tell this deep into the article, we also need to work out how we handle our animations when the component first loads. On this first render, we don't want any of our animations to fire.

To fix this, we'll need to keep track of whether we're in our first render. For this, we can use a useRef hook together with a useEffect hook that sets the ref's value back to false after the initial render.

export function RotatingIconButton({ children }) {
  /* snip */

  const isInitial = React.useRef(true)

  React.useEffect(() => {
    isInitial.current = false
  }, [])

  return <Button onClick={cycleCurrent}>{/* snip */}</Button>
}

To make use of this value, we'll give our Icon component one more prop, isInitial, that sets its animation duration to zero when isInitial is true.

const Icon = styled.div`
  position: absolute;
  top: 0px;
  height: 100%;
  width: 100%;
  display: flex;
  align-items: center;
  justify-content: center;
  animation-fill-mode: forwards;
  animation-duration: ${(props) => (props.isInitial ? 0 : 400)}ms;
  animation-name: ${(props) => (props.isCurrent ? riseIn : riseOut)};
`

And finally we can pass isInitial in through the Icon's props.

export function RotatingIconButton({ children }) {
  /* snip */

  const isInitial = React.useRef(true)

  React.useEffect(() => {
    isInitial.current = false
  }, [])

  return (
    <Button onClick={cycleCurrent}>
      {Children.map(children, (child, i) => {
        const isCurrent = i === current

        return (
          <Icon key={i} isInitial={isInitial} isCurrent={isCurrent}>
            {child}
          </Icon>
        )
      })}
    </Button>
  )
}

Final Component

And that's it! Here it is, our final component in a sandbox:

Now this isn't exactly how I implemented my theme switching button on this blog, but it's the basic idea. To make it work for your site, you might have to pass along events to your button through its props, especially if you plan on doing more with clicks than just switching the icon. Alternatively, you could use custom hooks inside of the component to control a theme or update the current state if the theme changed from elsewhere.

If the tricky part was just the animation, then you should be good to go.

Thanks for reading, and good luck!


  1. A cousin of the microinteraction is something I like to call the "fidget interaction", like the famous chat room gem in the Diablo video game. While microinteractions tend to reward or acknowledge certain user behaviors, fidget interactions are pointless: they don't do anything except give us something to do. Try hovering over the black box at the top left of the header.↩
  2. We could define these keyframes in a CSS file and just reference these animations by name, but since we're already using styled-components, let's stick to its way of handling keyframes. For the regular approach, see MDN's excellent guide to Using CSS Animations.↩
